10M Diesel Rough Terrain Scissors

The LGMG SR1218D-RT is a rough terrain diesel scissor lift with an 11.9-metre platform height. It is designed for outdoor high-reach elevated access across uneven, sloped, or unpaved ground conditions. The machine is commonly used on commercial construction sites, steel erection projects, cladding installations, industrial facility builds, and exterior maintenance works.

Features

  • Four-wheel drive system with oscillating axle for rough terrain mobility
  • Powerful diesel engine
  • Foam-filled rough terrain tyres
  • Auto-levelling hydraulic outriggers for stability on uneven ground
  • Roll-out platform extension deck for increased workspace and reach
  • Fold-down guardrails for reduced overhead clearance during transport
  • Proportional drive and lift controls
  • Emergency descent lowering system
  • On-board diagnostic system for quick troubleshooting

Uses

  • Exterior building construction and structural steel installation
  • Cladding, roofing, and facade installation
  • Electrical, piping, and mechanical overhead infrastructure installation
  • Building maintenance, washing, and painting on unpaved sites
  • Civil infrastructure and commercial construction works

Specifications

  • Working Height: 13.90 m
  • Platform Height: 11.90 m
  • Platform Dimensions (Retracted): 2.79 m x 1.60 m
  • Platform Extension Length: 1.52 m
  • Overall Length: 3.76 m
  • Overall Width: 1.79 m
  • Overall Height (Guardrails Up): 2.70 m
  • Overall Height (Guardrails Folded): 2.04 m
  • Wheelbase: 2.29 m
  • Ground Clearance: 0.23 m
  • Weight: 5,120 kg
  • Lift Capacity (Overall): 365 kg
  • Lift Capacity (Extension Deck): 140 kg
  • Occupancy Rating (Indoor / Outdoor): 3 Persons / 2 Persons
  • Engine Type: Kubota diesel engine
  • Power Output: 18.5 kW (24.8 HP)
  • Fuel Type: Diesel
  • Fuel Tank Capacity: 53 L
  • Hydraulic Tank Capacity: 70 L
  • Gradeability: 35%
  • Turning Radius (Outside): 4.75 m

Transport Requirements

  • Delivery Available

Recommended PPE

  • Steel-capped boots
  • Safety helmet
  • Safety harness and lanyard (where required)
  • Gloves
  • Hearing protection

Optional Attachments

  • Safety Harness


Downloadable Documents

  • Operator's Manual


  • Spec Sheet
