20KVA Silenced Generator
The Shindaiwa DG20MKM is a 20 kVA single-phase silent diesel generator designed to supply clean and stable power for temporary site operations, back-up power, and sensitive electronic equipment. It features a sound-proofed acoustic canopy for low-noise performance in urban and noise-sensitive environments. The generator is commonly used on construction sites, civil works, commercial operations, outdoor events, and for emergency standby power.
Features
- Ultra-silent sound-attenuated canopy enclosure
- Environmental bunded base frame to prevent fluid spills and leaks
- Clean-burning, water-cooled multi-cylinder diesel engine
- Brushless alternator providing stable voltage regulation for sensitive loads
- Automatic safety shutdown system for low oil pressure, high water temperature, and door access
- Single-point lifting frame and integrated forklift pockets for site mobility
- Lockable side access doors for equipment security
- Heavy-duty industrial chassis frame
Uses
- Prime power for construction sites, site sheds, and work vehicles
- Emergency backup power for commercial, agricultural, and residential sites
- Powering single-phase site distribution boards, tools, and heavy machinery
- Outdoor events, festivals, and temporary installations
- Civil infrastructure and utility works
Specifications
- Prime Power Rating: 18.0 kVA / 14.4 kW
- Standby Power Rating: 20.0 kVA / 16.0 kW
- Voltage: 240 V
- Current Output: 75.0 A
- Frequency: 50 Hz
- Phase: Single Phase
- Power Factor: 0.8
- Engine Type: Multi-cylinder water-cooled diesel engine
- Fuel Type: Diesel
- Fuel Tank Capacity: 70 L
- Fuel Consumption (at 100% load): 4.8 L/h
- Run Time (at 100% load): 14.6 hours
- Run Time (at 75% load): 19.4 hours
- Overall Length: 1,540 mm
- Overall Width: 720 mm
- Overall Height: 980 mm
- Dry Weight: 585 kg
- Operating Weight: 645 kg
- Noise Level (at 7m): 59 dB(A)
Transport Requirements
- Delivery Available
Recommended PPE
- Steel-capped boots
- Hearing protection
- Gloves
Optional Attachments
- Heavy-duty 240V extension leads
- Distribution boards
