20KVA Silenced Generator

The Shindaiwa DG20MKM is a 20 kVA single-phase silent diesel generator designed to supply clean and stable power for temporary site operations, back-up power, and sensitive electronic equipment. It features a sound-proofed acoustic canopy for low-noise performance in urban and noise-sensitive environments. The generator is commonly used on construction sites, civil works, commercial operations, outdoor events, and for emergency standby power.

Features

  • Ultra-silent sound-attenuated canopy enclosure
  • Environmental bunded base frame to prevent fluid spills and leaks
  • Clean-burning, water-cooled multi-cylinder diesel engine
  • Brushless alternator providing stable voltage regulation for sensitive loads
  • Automatic safety shutdown system for low oil pressure, high water temperature, and door access
  • Single-point lifting frame and integrated forklift pockets for site mobility
  • Lockable side access doors for equipment security
  • Heavy-duty industrial chassis frame

Uses

  • Prime power for construction sites, site sheds, and work vehicles
  • Emergency backup power for commercial, agricultural, and residential sites
  • Powering single-phase site distribution boards, tools, and heavy machinery
  • Outdoor events, festivals, and temporary installations
  • Civil infrastructure and utility works

Specifications

  • Prime Power Rating: 18.0 kVA / 14.4 kW
  • Standby Power Rating: 20.0 kVA / 16.0 kW
  • Voltage: 240 V
  • Current Output: 75.0 A
  • Frequency: 50 Hz
  • Phase: Single Phase
  • Power Factor: 0.8
  • Engine Type: Multi-cylinder water-cooled diesel engine
  • Fuel Type: Diesel
  • Fuel Tank Capacity: 70 L
  • Fuel Consumption (at 100% load): 4.8 L/h
  • Run Time (at 100% load): 14.6 hours
  • Run Time (at 75% load): 19.4 hours
  • Overall Length: 1,540 mm
  • Overall Width: 720 mm
  • Overall Height: 980 mm
  • Dry Weight: 585 kg
  • Operating Weight: 645 kg
  • Noise Level (at 7m): 59 dB(A)

Transport Requirements

  • Delivery Available

Recommended PPE

  • Steel-capped boots
  • Hearing protection
  • Gloves

Optional Attachments

  • Heavy-duty 240V extension leads
  • Distribution boards
