4 Inch Self-Prime Diesel Pump

The Atlas Copco VAR 4-250 (Varisco series) is an automatic self-priming centrifugal trash pump mounted on a heavy-duty trailer chassis, designed for dewatering and solids handling. Powered by a water-cooled multi-cylinder diesel engine, it utilizes a semi-open impeller and vacuum-assisted or centrifugal rapid-priming technology to pump water containing large suspended solids, sand, and mud. The unit is commonly used across civil construction sites, quarrying operations, mine dewatering, municipal storm water management, and emergency flood response.

Features

  • Automatic rapid self-priming system capable of priming dry from up to 7.5 metres
  • Semi-open, high-efficiency impeller designed for handling large spherical solids without clogging
  • Multi-cylinder water-cooled diesel engine with integrated engine protection shutdowns
  • Abrasion-resistant ductile iron pump casing and mechanical seal system with oil-bath lubrication
  • Heavy-duty sound-attenuated acoustic canopy designed for low-noise operation in built-up areas
  • Integrated road-ready trailer chassis fitted with mechanical overrun brakes, tow hitch, and jockey wheel
  • High-capacity internal diesel fuel tank with fully bunded environmental base to catch fluids
  • Digital control panel monitoring engine speed, operating temperature, oil pressure, and hours

Uses

  • Dewatering excavation sites, foundation footings, and pipeline trenches
  • Pumping muddy water, slimes, and liquids containing suspended solids
  • Groundwater level management and wellpoint dewatering
  • Municipal sewage bypass pumping and storm water drainage
  • Emergency flood relief and retention basin water transfer
  • Quarry and open-cut mine pit dewatering

Specifications

  • Suction / Discharge Size: 100 mm (4 inches)
  • Maximum Flow Rate: 250 m³/h (approx. 4,160 L/min)
  • Maximum Total Head: 30 m
  • Maximum Solids Handling Diameter: 75 mm
  • Maximum Suction Lift: 7.5 m
  • Impeller Type: Semi-open trash handling impeller
  • Priming System: Automatic vacuum/diaphragm assisted priming
  • Engine Type: Multi-cylinder water-cooled diesel engine
  • Fuel Type: Diesel
  • Fuel Tank Capacity: 170 L
  • Fuel Consumption (at 100% load): 5.5 L/h
  • Run Time (at 100% load): Approx. 30 hours
  • Run Time (at 75% load): Approx. 40 hours
  • Overall Length: 2,450 mm
  • Overall Width: 1,450 mm
  • Overall Height: 1,550 mm
  • Operating Weight: 1,480 kg

Transport Requirements

  • Trailer Mounted or Skid Mounted – Vehicle with a 3T towing capacity required or Delivery Available

Recommended PPE

  • Steel-capped boots
  • High-visibility clothing
  • Hearing protection
  • Eye protection
  • Gloves

Optional Attachments

  • 100 mm (4") heavy-duty wire-reinforced suction hose (6 m lengths with Bauer or Camlock couplings)
  • 100 mm (4") flexible layflat discharge hose (20 m lengths)
  • Suction strainers / foot valves
