Plate Compactor Medium 80kg

The Wacker Neuson VPh70 is a single-direction petrol soil compactor designed for the compaction of granular soils, gravel, sand, and asphalt. It features a compact baseplate for operating in tight or confined work areas. The machine is commonly used for trench work, pipe laying, footpath preparation, driveway sub-bases, and small asphalt patching repairs.

Features

• High-strength ductile iron baseplate with rounded edges to prevent gouging
• Ergonomic, vibration-dampened guide handle to reduce hand-arm vibration
• Central single-point lifting bracket for overhead transport
• Tough protective engine pipe frame to guard against jobsite impact
• Fully enclosed belt guard to protect driving components from debris
• Straight-sided plate design for close-up compaction against walls, kerbs, and footings

Uses

• Granular soil, sand, and gravel compaction
• Asphalt compaction and driveway repairs
• Trench backfilling and pipeline bedding
• Sub-base compaction for paving, slabs, and footpaths
• Landscaping and residential site preparation

Specifications

• Baseplate Width: 500 mm
• Baseplate Length: 538 mm
• Overall Length (Operating): 1,025 mm
• Overall Width: 500 mm
• Overall Height: 940 mm
• Operating Weight: 74 kg
• Engine Type: Air-cooled, single-cylinder 4-stroke petrol engine
• Engine Model: Honda GX160
• Power Output: 3.6 kW (4.8 HP)
• Fuel Type: Unleaded Petrol
• Fuel Tank Capacity: 3.6 L
• Centrifugal Force: 19.8 kN
• Vibration Frequency: 100 Hz
• Max Forward Travel Speed: 28 m/min
• Max Surface Capacity: 840 m²/h

Transport Requirements

• Suitable for transport in a ute, van or small trailer.

Recommended PPE

• Steel-capped boots
• Hearing protection
• Gloves
